Cat6a RJ45 High toughness Shrapnel Lan Cable
Cable Specification: Packing Information: 3.Outside carton size:52cmx41cmx41cm 4.Weight:7.5kgs~14kgs per box (depend on different specification) 5.OEM/ODM Packing is available Twisted pair: 4P Conductor Type: Solid Conductor
size :22AWG/23AWG/24AWG Conductor Material: OFC/BC/CU/CCAG/CCA/CCS Center Splitter: YES Shield: Unshielded Jacket Layer: Single Print word on cable: As Clients' Request Drain wire: NO Braid: NO Length: 305M /or as your request Jacket Color: Optional Electrical Characteristic: Impedance: 100±15Ω at 1~250MHz Stretching Resistance: (max)400N NVP: 66% Bending Radius: (min)8 times the outer diameter Operating Temperature: -40 °C - +70 °C Retardation Deviation: (max)45ns/100m Reference Standard: YD/T1019-2001, ANSI/TIA/EIA-568B, ISO/IEC11801 Certification: CE,ROHS Application: Computer Network Cabling Project / Broadband Network Communication
Ethernet Network / Audio and Data Transmission
1.305m/box,pull out box ,2boxes/ctn
2.Pull out box size:40cmx40cmx24cm
