FC-SC fiber optic adapter

Details

FC-SC fiber optic adapter


Good inerchangeability
Environmentally Stable and Reliable
Accurate Size
Excellent Return Loss
Applicable standard: IEC 61754-13
Complete Hybrid adapter
Insertion Loss ≤0.2dB
Retentiveness 200-600g
Mating Durability1000 times≤ 0.2dB
Exchangeability: < 0.2dB
Salt Spray: &le; 0.2dB
Sleeve material: ceramic / metal
Temperature Rang -40 to +85


SPECIFICATIONS (Hybrid type adapter)

ITEMPARAMETER
Applicative adapter typeSC,LC,FC,ST,MU,D4,DIN
Fiber modeSingle modeMulti-mode
Adapter colorBlue, green, metalBeige, metal
Test wavelength1310nm, 1550nm850nm, 1300nm
Insertion Losstypical&le;0.15dB,Max&le;0.20dBtypical&le;0.15dB,Max&le;0.20dB
Repeatability&le;0.10dB
Interchangeability&le;0.20dB
Durability&le;0.20dB Max change,1000 mating
ChannelsSimplex,Duplex,4channels
Body materialPlastic or metal
Sleeve materialCeramic(ZrO2) or Customized
Operating Temperature-20&ordm;C to +70&ordm;C
Storage Temperature-40&ordm;C to +85&ordm;C
