ODC outdoor fiber optic patch cord assembly protected branch cable for 3G/4G base station

Products Category : Waterproof Fiber Series Products > Waterproof Fiber Patch Cord

INQUIRY

Details

ODC outdoor fiber optic patch cord assembly protected branch cable for 3G/4G base station

Price-Competitive
Low Insertion Loss & PDL
Factory-terminated and Tested

Features

• Robust fiber-optic connector for 2 and 4 channels with screwed mating mechanism

• IP68 protection, salt-mist proof, and EMI protection

• High shock, vibration, and mechanical resistance

• Broad temperature range and wide range of indoor and outdoor cables

• Easy, reliable and cost-effective installation

Specifications

1.ODC-2, ODC-4 channels can select
2. PVC, LSZH cables are available
3.Waterproof, dust proof and corrosion resistan

HOMK-Fiber fiber optic products for harsh environment are designed to withstand severe mechanical loads, high thermal exposure, and demanding environments like rain, salt and splash water.

ODC harsh environment cable assemblies are installation-friendly for fixed or mobile applications and transmit reliably data over long distances under severe environmental conditions.

Pecification

Fiber Core	2,4,6,8 etc
Mode	Singlemode			Multimode
Operating Wavelength(nm)	1310/1550			850/1310
Polishment	UPC	APC		UPC
Insertion Loss(Max.dB)	0.7			0.6
Return Loss(Min.dB)	55		60	35
Mating times	500 Min
Durability(Max.dB)	0.2
Reaptability(Max.dB)	0.5
Operating Temperature(℃)	-40~+85
Storage Temperature(℃)	-40~+85
