SC/UPC-FC/UPC SM OTDR Launch Cable Box

Details

Single Mode OTDR Launch Cable Box with FC and SC Connector,good price OTDR Test Box


Designed to aid in the testing of fiber optic cable when using an OTDR.  The OTDR Launch Cable Box is used with Optical Time Domain  Reflectometers (OTDRs) to help minimize the effects of the OTDRs  launch pulse on measurement uncertainty. Available in many different  configurations and fiber lengths.


Features



Pulse Suppressor, Launch Box, Delay Line, Installation/Testing, Training, Calibration
Compound Latch for positive seal and easy opening with locking feature
Non¬metal construction will not dent, corrode, or conduce electricity
Water and dust prove allowing the unit to be taken into almost any environment
Case can house up to 2,000 meters of fiber
Auto Purge Valve for changes in altitude and temperature

Specification:
Length x Width x Height
9.37" x 5.56" x 2.62"    (238x141x66mm)
Material
SR Polypropylene
Weight
0.75 kg (without fiber)
Operating temperature
-40° to +55°C
Typical Loss
< 0.5dB @ 1310nM for 1000 meters
