Single Mode OTDR Launch Cable Box with SC Connector,good price OTDR Test Box
Designed to aid in the testing of fiber optic cable when using an OTDR. The OTDR Launch Cable Box is used with Optical Time Domain Reflectometers (OTDRs) to help minimize the effects of the OTDRs launch pulse on measurement uncertainty. Available in many different configurations and fiber lengths.
Features
Pulse Suppressor, Launch Box, Delay Line, Installation/Testing, Training, Calibration
Compound Latch for positive seal and easy opening with locking feature
Non¬metal construction will not dent, corrode, or conduce electricity
Water and dust prove allowing the unit to be taken into almost any environment
Case can house up to 2,000 meters of fiber
Auto Purge Valve for changes in altitude and temperature
Compound Latch for positive seal and easy opening with locking feature
Non¬metal construction will not dent, corrode, or conduce electricity
Water and dust prove allowing the unit to be taken into almost any environment
Case can house up to 2,000 meters of fiber
Auto Purge Valve for changes in altitude and temperature
Specification:
Length x Width x Height | 9.37" x 5.56" x 2.62" (238x141x66mm) |
Material | SR Polypropylene |
Weight | 0.75 kg (without fiber) |
Operating temperature | -40° to +55°C |
Typical Loss | < 0.5dB @ 1310nM for 1000 meters |
