Fiber Microscope(HK-JJ)

Fiber microscope HK-JJ by magnifying 200~400 time of the objects, you can identity defects and scratches on the endface of connectors. It is your the best choice for endface inspection.
HK-JJ fiber microscope comes along with portable 3.5 inch high resolution LCD monitor,it can work over 8 hours after recharge.There are also all kinds of tips which make Easyget to meet different requirements on inspecting.




HK-JJ uses aviation electrical plugs instead of USB connector compared to the previous version. The image of easyget will stay clean and stable even in the harsh environment.







Tips of Easyget

2.5mm Universal 1.25mm Universal SC/UPC LC/UPC FC/UPC ST/UPC
2.5mmAPC Universal 1.25mmAPC Universal MU/UPC SC/APC LC/APC E2000/APC

Inspection of various products


EG4       EG6


4 All Connector Inspection including MT

HK-JJ has equipped kinds of tips that is able to inspect connector, transceivers modules (SFP, QSFP) and optical components(TOSA, ROSA ). We have designed new MT adaptors that is able to inspect MPO and MTP products such as MPO, MTP connectors in adaptors, 40G, 100G modules and so on.HK-JJ is suitable for maintaining high density data center of next generation.


3 New Data Acquisition Card and Software

The new acquisition card is compatible for more operation system and has higher image quality. The image capture software has more functions such as auto brightness, auto analysis (optional).HK-JJ is able to connect to desktop monitor as well (optional conversion cable needed).



2 Stable and Durable Connection


1 Longer Life, Better Image Quality

We have improved the structure of fiber microscope HK-JJ  and provide longer life term. The whole microscope has a sealed structure that will keep the optical component clean even in harsh environment.


Item Parameters
Magnification 400X or 200X
Output Format PAL
Power Consumption  3W
Portable Monitor  3.5" TFT
Operation Temperature -10~50℃
Storage Temperature -20~50℃
Power Supply Rechargeable 12V battery or DC IN
Life time after charge 8h
Size  Monitor 205mm*94mm*25mm
Microscope 23mm*160mm
Model Display size of 125um fiber core at 8" monitor Range of sight at 8" monitor Display size of 125umfiber core at 3.5" monitor Range of sight at 3.5" monitor Resolution
  Φ44 mm 340.9~454.5um Φ20 mm 312.5~425um 2.5um
Easyget 400 Φ58 mm


Φ26 mm 240~327um 1.5um
