Details
HS-30 Optical Fiber Cleaver
This optical fiber cleaver is available with a single fiber adapter for 250 to 900 micron coated single fibers. It is a simple operation for the user to remove or install the single fiber adapter and alternate between mass and single fiber cleaving.
• Compact body& light weight
• High Precision Cleaves
• 250um Coated or 900um Buffer fiber
• Singlemode
Specification
Bare fiber diameter | 0.25mm~0.9mm | ||
Outcoat diameter | 1.25mm | ||
Cutting angle | 0.5° | ||
Cleaving Length | 250um: 9~16mm, 900um: 10~16mm | ||
Blade Life | 48000 times | ||
Fiber Core | Single | ||
Material | stainless steel | ||
