Shenzhen Homk Telecom Tech Co., Ltd.

MPO Fiber Optic Adapter with ears

Details

MPO Fiber Optic Adapter with ears


Fiber optic adapters (also known as bulkheads) are used to join two fiber optic patch cables together.

They are available for use with either singlemode or multimode patch cables.

Homk provides an extensive line of fiber optic adapters that offer superior low loss performance with very high repeatability. like SC Fiber Optic Adapter, LC Fiber Optic Adapter, FC Fiber Optic Adapter, ST Fiber Opitc Adapter, MU Fiber Optic Adapter, MTRJ Fiber Optic Adapter, E2000 Fiber Optic Adapter, D4 Fiber Optic Adapter

Features:

Good inerchangeability
Environmentally Stable and Reliable
Accurate Size
Excellent Return Loss

Applicable standard: IEC 61754-13

Complete Hybrid adapter

Technical Standard:

Insertion Loss ≤0.2dB

Retentiveness 200-600g

Mating Durability1000 times≤ 0.2dB

Exchangeability: < 0.2dB

Salt Spray: &le; 0.2dB

Sleeve material: ceramic / metal

Temperature Rang -40 to +85



Parameter
Unit
LC, SC, FC, MU, ST, SC-ST, FC-ST, FC-SC, FC-LC, FC-MU
MTRJ
E2000
SM
MM
SM
MM
SM
PC
UPC
APC
PC
PC
UPC
PC
PC
APC
Insertion Loss (Typical)
dB
&le;0.3
&le;0.2
&le;0.3
&le;0.2
&le;0.3
&le;0.2
&le;0.2
&le;0.3
&le;0.3
Return Loss
dB
&ge;45
&ge;50
&ge;60
&ge;30
&ge;45
&ge;50
&ge;35
&ge;55
&ge;75
Exchangeability
dB
&le;0.2
&le;0.2
&le;0.2
Repeatability
dB
&le;0.2
&le;0.2
&le;0.2
Durability
Time
>1000
>1000
>1000
Operating Temperature
&deg;C
-40~75
-40~75
-40~75
Storage Temperature
&deg;C
-45~85
-45~85
-45~85
