Rack Mount Drawer Type Fiber Terminal Box 24 core
Product Introduction:
The
Fiber Optic Terminal Box is a kind of fiber optic management products
used to distribute and protect the optical fiber links in FTTH Network.
It is available for the distribution and terminal connection of various
kinds of optical fiber system. These units are available in sizes that
fit the most common distribution requirements. we provide is a kind of
high quality, micro sized fiber optical termination box made of quality
cold-rolled steel sheet and undergoes static plastic spraying treatment.
The box can be installed in the indoor rack mount chassis and the
indoor wall and terrace
Introduction:
1.19'' standard structure, rack mounting.sliding design,nice appearance.
2• A pothook convenient to install and dismantle
3• Splice tray could be piled one upon another, flexible to turn
4• Unique structure, reasonable layout, adequate room for operation
5• Adjustable clamp seal ring and reinforce configuration
6• With excellent seal performance, preventing water from entering effectively
7• Rack mount in optical distribution frame ODF
Application:
1.Fiber to the home(FTTB)
2.Optical network
3.Local area networks
4.Wide area networks
1.19'' standard structure, rack mounting.sliding design,nice appearance.
2• A pothook convenient to install and dismantle
3• Splice tray could be piled one upon another, flexible to turn
4• Unique structure, reasonable layout, adequate room for operation
5• Adjustable clamp seal ring and reinforce configuration
6• With excellent seal performance, preventing water from entering effectively
7• Rack mount in optical distribution frame ODF
Application:
1.Fiber to the home(FTTB)
2.Optical network
3.Local area networks
4.Wide area networks
5• Telecommunication network
6• Central office optical cable system
7• Premise fiber network
Technical Information:
Max capacity : 12,24,32,48,64,72,96 splices
Available adapter port: ST,FC,SC,LC
Suitable for ribbon and bunchy fiber cable
19 inches; 1U for 12 splices, 24 splices,2U installation for 32 splices, 48 splices, and 3U for 64, 72 & 96 splices.
7• Premise fiber network
Technical Information:
Max capacity : 12,24,32,48,64,72,96 splices
Available adapter port: ST,FC,SC,LC
Suitable for ribbon and bunchy fiber cable
19 inches; 1U for 12 splices, 24 splices,2U installation for 32 splices, 48 splices, and 3U for 64, 72 & 96 splices.
Operating/Storage Temperature: -20 to +80°C
