ARC Fusion Splicer HK-740 FTTH

Details

ARC Fusion Splicer HK-740 FTTH


1. It can applicable fibers such as SM/MM/DS/NZ-DS/EDF.
2. 8 Sec. splice time, 40 Sec. tube-heat time.

3. Reversible monitor with control panel on each side.
4. Compact & Light weight (3.3kg with battery).
5. SYSTEM TEST ensures the best working condition.
6. Auto check fiber end face.
7. Auto calibrate parameters.
8. Store 8000 groups of splice results, and can connect to computer
9. 8 Kind of Language options: English, Korean, Russian, Portuguese, French, Spanish, German, Chinese.
10. Large capacity internal battery ( Liion battery 12V 10,000mAh can guarantee the outdoor work. Normally when the user operate by the right way, the battery can really offer more than 200 times of continuous splices and heats when it is used in outside.)

Specifications:

Applicable fibers;

SM,MM,DS,NZ-DS,EDF

Cladding diameter:

100 to 150um

Coating diameter:

100 to 1000um

Fiber cleaved length:

8-22mm (standard)

Splicing mode:

Auto & Manual

Average splice loss:

0.02dB(SM),0.01dB(MM),0.04dB(DS),0.04dB(NZDS)

Return loss:

≥ 60dB

Environment conditions:

-25~+50°C (operation temperature), 0~95%RH (humidity), 0~5000m (altitude)

Storage environment:

-40~ +80°C (temperature) , 0~95%RH (humidity)

Protection sleeve length:

20mm ,40mm ,60mm

Tension test:

2.0N (Standard)

Language:

English, Chinese, Korean, Russian,Spanish etc.

Interface:

RS232 interface & video output

Power supply:

AC adaptor: 85~260V input voltage

Internal battery: 12V voltage, 10Ah, more than 200 times of continuous splices and heats

DC adaptor: 12V voltage,optional multipurpose external battery

Dimensions:

142(W)×122(H)×138(D)mm

Weight:

3.3kg

Parts detail of DVP-740 Single Fiber Fusion Splicer:

Part name

Material

Supplier

Technical standard

Camera

CCD

SONY Japan

SONY Enterprise standard

CPU

44BOX

Samsung Korea

Samsung Enterprise standard

Guide Rail

Stainless steel

IKO Japan

IKO Enterprise standard

Limit Switch

GLS53

Sharp Japan

Sharp Enterprise standard

Bearing

Stainless steel

THK Japan

THK Enterprise standard

Motor

ULN2003

Philips

Philips Enterprise standard

Standard package of single fiber DVP-740 Fusion Splicer:

Main body

Internal battery

charger

Spare Electrodes

Cooling tray

Manual instruction

Cary case

Fiber cleaver

Fiber stripper

AC adapter

AC power cord
