Fiber polishing mahine(HK-30Y)

Details

HK-30Y CE Fiber Polishing Machine With Two Japan Motors & Gear Working


HK-30Y fiber polishing machine all components from Japan,included switch,motors,tray,spring,shell etc. So the quality is very well.



HK-30Y with following features:

High-yield Operation
It is capable of polishing up many ferrules at once in a short time. (The number of
ferrules varies slightly depending on the types of connectors.)


Easy Operation
Both maintenance and operation are remarkably easy and require no special skills.


Wide Range of Application
Applicable to FC, SC,LC,ST,E2000,MPO,MTP,MTRJ and various other connector types in high-physical contact,





Parameter



Pressure way4 coil springInsert Loss 0.3 dB (SM)
0.2 dB (MM)
Polishing capacity(max)SC, FC, ST: 20, 48 units LC: 24, 48unitsReturn Loss50 dB (PC)
60 dB (APC)
Polishing connector typeFC, SC, ST, LC, MU, MTP, MPO, MTRJ and so onRadius10~25mm
Motor speed90rpm rotation, 2rpm revolutionOffset50 μ M
Dimension230*230*255mmUnder cut50nm
Film size5' 'Repeatability  0.1dB
Weight24KGInterchangeability0.2 dB
Input voltage100-120VAC, 50/60Hz or 220-240VAC, 50/60HzWorking Situation Temperature  -10— +40º C
Polishing cycle2.83minsHeavy punch500g or 250g
Polishing chassis diameter130mm
Polishing time setting0-3min
Counterweight pressure  2.1~3.6kgf/cm
Time Range0-300S
Polishing Time 2 min. (quick assembly type)
 3-4 min. (standard connectors)
Pressure Range0~5kg
Precession Speed1.5rpm
