KL-510E Handheld Fiber Fusion Splicer

Details

KL-510E Handheld Fiber Fusion Splicer


Feature:

Core-Core & Clad-Clad Alignment

PAS Technology

X&Y views dispaly or X/Y single display

Handheld & portable

Size: 193mmx125mmx85mm

SOC available

3-in-one fiber clamp

3.5 inch color LCD

Software update via USB port



Specification

Applicable fibers

SM  MM  DS  NZDS

Fiber diameter

Cladding diameter:80-150μm

Fiber count

Single

Fiber cleaved length

12-16mm (Coating diameter:250μm)

Actual average splice loss

0.02dB(SM),0.01dB(MM),0.04dB(DS),0.04dB(NZDS)

Typical splicing time

Typical 9 sec (standard SM fiber)

Return loss

>60dB

Splicing mode

Auto Calibrate Normal Special

Fiber aligning method

Meticulous,Core,Clad,Manual

Splicing program

53 (templet), 40(user)

Tube heating program

9 (templet),24(user)

Tube typical heating time

Typical 30 sec

Protection sleeve length

60mm, 40mm

Storage of splice result

4000 results, 20 parameter per result

Fiber image magnification

120X (X or Y view),60X  (X and Y view)

Battery capacity

Typical 150 cycles (splice/tube heaty)

Monitor

3.5 inch color LCD monitor

Tension test

2N

Electrode life

2500

Terminal

USB

Power supply

AC 100-240V with AC adapter

Inner Li-battery (2600mAh)  DC 13.5V

Operating condition

0-5000m above sea level, -10-50°

Max wind velocity of 15m/s

Dimension

193mm(L)×125mm(W)×85mm(H)

Weight

1.1Kg including battery
