45 Degree Fiber Optic Connector

Details

45 Degree Fiber Optic Connector Boot

Specifications

1.SM MM Ferrule

2.45 90 degree boot

3.0.9 / 2.0 / 3.0mm Boot

4.Blue Beige Green Red Black White Boot

5.RoHS, SGS Complia

Fetures

> Compliant with Telcordia,GR-326-CORE,TIA/EIA and IEC

> Superior Quality Standard PC/UPC/APC Polishing

> Customer Defined Specifications

> RoHS Compliance

 > Environmental Stable

 > Low Insertion Loss & back Reflection

Applications

> CATV Networks

> Telecommunication Networks

> Local Area Networks

> FTTH and FTTx

> Active Device Termination

> Testing Instruments


2.   Specifications:



Items

Single mode

Multimode

PC

UPC

APC

62.5/125

50/125

50/125 10G

Insertion Loss

<0.2dB

<0.3dB

Return Loss

>45dB

>50dB

>60dB

35dB

Durability

<0.1dB typical change,500 matings

Operating Temperature

-40 to +75

-40 to +75

Ferrule Hole Sizes

125.0+1/-0um,   Conentricity:1um

125um,Conectricity:1   to 3um

125.3+1/-0um,   Conentricity:1um

127um,Conectricity:1   to 3um

125.5+1/-0um,   Conentricity:1um

128um,Conectricity:1to   3um

126.0+1/-0um,   Conentricity:1um
