Shenzhen Homk Telecom Tech Co., Ltd.

Blue Cable Duct Rodder

Details

Blue Cable Duct Rodder


Duct rodder Feature:
1.Great rigidity and strength
2. Light & easy to use
3. Excellent flexibility force
4. Quickly delivery
5. Safe, non conductive and no kink
6. Anticorrosion, good elasticity, long working life

Duct rodder Structure:
1. Fiber glass rod inner: Extruded by fiber glass and unsaturated polyester resin at high temperature.
2. Fiber glass rod outer: Medium density ABS resin for the insulating and jacketing of cables.
3. Assembly: metal frame sprayed paint; rubber wheels assembly for easy transportation; Guide rollers and
the  right parts for rotary coupling; parking brake for the flexible    rod. 4.  Copper wire inside is optional which is for tracing easily.
5.  Rolling bearing cage for mobility will be light and easy to use in    the  field. 6. Feed device allows rod to feed out or be back
with easy push or pull of rod

                                               Technical Data of Duct rodder

Specification

Rod Diameter (mm)

Φ4,Φ5,Φ6,Φ8, Φ9,Φ10,Φ11,Φ12,Φ13,Φ14,Φ15,Φ16

Rod Length (m)

30m,50m,60m,80m,100m,120m,150m,180m,200m,250m,300m,350m,400m,500m

Frame Spec.(mm)

1300x450x1330,1200x420x1220,980x350x1000,680x240x700,420x180x400

Material:

Fiber glass rod inner,

Extruded by fiber glass and high strength resin at high temperature

Fiber glass rod outer

High Density polyethylene coating

Metal Frame

Steel with high-temperature sprayed plastic or hot dip galvanized

Physical Property

Fiber glass content

75-80%

Density

>1.9gr/cm3

Working environment

-40°C to +80°C

Minimum Pulling strength

4000N +/-5%

Consistency of rod

137gr/m

Flexural Modulus

>46.500Mpa

Elongation at break

2.5-3%

Min Bending Radius

388mm
