Shenzhen Homk Telecom Tech Co., Ltd.

Cat6a 4 Pairs SSTP Network Cable

Details

Cat6a 4 Pairs SSTP Network Cable


SFTP CAT6A CABLE

CABLE CAT6A FFTP



1x 4 PAIRES SOLID COPPER (100% COPPER) AWG23 100 OHMS LSZH

GREEN LSZH JACKET(RAL 6018)



Each pair must be Aluminum foiled separately

Overall shielding with Aluminum foil, tinned copper drain wire



500M/WOOD DRUM

WOODEN PALLET PACKAGE



OEM order is welcome



· Includes:

BC conductor

F-PE insulation

Twisted pair screen

Drain wire

Overall screen

Rip cord

PVC sheath



·  Conductor:

 Material: solid bare copper

 Number of pairs: 4 pairs

 AWG: 24

Conductor diameter: 0.575 ±0.003mm



·Insulation:

Material: F-PE

Diameter: 1.35 ±0.005mm

Average thickness: 0.3875mm

 Minimum point thickness: 0.3870mm

Twisted pair screen: AL foil (25%)

Drain wire: Ø0.4mm TC

Overall screen: AL foil (25%)

Jacket rid cord: optional

 Sheath:

Material: PVC or LSOH

Nominal diameter: 8.5 ±0.2mm

Average thickness: 0.65mm

Minimum point thickness: 0.645mm

Operating temperature: -20 to 75°C

Minimum bend radius (install): (OD) 8mm

Flame test: CMX, CM, CMR and IEC60332-1
