Cat7 Aluminum Braided Shielded SSTP Network Cable

Details

Cat7 Aluminum Braided Shielded SSTP Network Cable

Descriptions Of Lan cable

Product Description:

Rated temperature:

60℃,75℃,90℃

Installation temperature:

-30℃~+50℃

Minimum bending radius:

8D

Reference Standard:

UL444,UL1581

Solid bare copper conductor

Pair shield with Alu foil

PVC/ LSZH jacket,RoHS/REACH Compliant

Comply to TIA/EIA-568-C.2-10,IEC61156-5,EN50173&ISO/IEC 11801

Feature&Advantages:

CAT6A  Cable is designed  for improve crosstalk performance between cables  applying in 1000Base-T  Ethernet with up to 500MHz  bandwidth,Skin-foam-skin insulation and  pair shield design make the  cable with excellent shielding&anti-EMI  performance.This cable  complies to all the requirements for CAT6A of   TIA/EIA568B-10&IEC61156.

Cable Construction (CAT6A)

Item No.



Construction



Nominal

Conductor

Dimension

(mm)

Nominal

Insulation

Diameter

(mm)

No.of Paris



Nominal

Cable

OD.

(mm)

Type of Jacket



216101

FFTP

0.570

1.35

4

7.6

PVC

216601

FFTP

0.570

1.35

4

7.6

LSZH
