E2000 PC Fiber Optic Connector SM 2.0mm
Product Name: Fiber Connector
Model:E2000
E2000 fiber connector Application
☆.WANs, LANs, CATV
☆.Metrology, Railway, Industry
E2000 fiber connector Characteristics:
☆.Zirconia ceramic ferrule fully protected by spring loaded shutter
☆.Push-pull locking mechanism for easy installation Color coded release levers
☆.Compliant with European (EN 186270) and International (IEC 61754-15) standards
☆.Tested and approved by Swisscom
E2000 fiber connector features
Secure transmission of high bit-rate protocols
Zirconia ceramic ferrule fully protected by spring loaded shutter
Push-pull locking mechanism for easy installation
Color coded release levers
Compliant with European (EN 186270) and International (IEC 61754-15) standards
Item | LC, SC, ST, FC, MTRJ, MU, SMA, E-2000, etc | ||
Type | Multi-Mode | Single-Mode | |
Light Characteristic | Operating Wavelength | 850nm& 1300nm | 1310nm & 1550nm |
Typical Insertion Loss | 0.2dB & 0.2dB | 0.2dB & 0.2dB | |
Mechanical Testing | Repeatability | ≤ 0.2dB | |
Exchange | ≤ 0.2dB | ||
Durability | > 1000 (Times) | ||
Temperature | Storage Temperature | 25 ~+85 | |
Operating Temperature | 25 ~+85 | ||
Length, Color, Out-Diameter, Fiber counts | According to the customers' requirement | ||
