SM&MM OTDR Optical Time Domain Reflectometer, Model# FHO5000-MD21
850/1300/1310/1550nm Wavelengths, 19/21/35/33dB Dynamic Range
- SM & MM OTDR,
- 7'' Screen With High Resolution
- Wavelengths: 850/1300/1310/1550nm
- Dynamic Range:19/21/35/33dB
- Event/ Attenuation Dead zone: 0.8M/ 4M/ 1M/ 4M
- Selectable Distance (Km): 4m-240km
- Print Report easily
- Connect to your computer with a cable
- With .sor software & A->B, B->A analysis software
- Real time & Averaging testing mode
- Free updating software
Specification:
| OTDR (MODEL# FHO5000-MD21) | |
| General Paramer | |
| Testing Wavelen | 850/1300/1310/1550 |
| Dynamic Range | 19/21/35/33dB |
| Event Dead Zone | 0.8m/1m MM/SM |
| Attenuation Dead | 4m/4m MM/SM |
| Pulse Width | Single mode: 3ns, 5ns, 10ns, 20ns, 50ns, 100ns, 200ns, 500ns, 1μs, 2μs, 5μs, 10μs ,20us Multi mode: 3ns, 5ns, 10ns, 20ns, 50ns, 100ns, 200ns, 500ns, 1μs, 2μs |
| Testing Range | Dead zone, 500m, 2km, 5km, 10km, 40km, 80km, 120km, 160km, 240km |
| Resolution | Minimum 0.25m |
| Linearity | ≤ 0.05dB/dB |
| Display Resolution | 0.01dB |
| Loss Threshold Step | 0.01dB |
| Loss Resolution | 0.001dB |
| Distance Resolution | 0.01m |
| Sampling Point | Maximum 128,000 points |
| Distance Accuracy | ± (1m+measuring distance×3×10-5+sampling resolution) |
| Data Storage | 40000 groups of curve |
| Internal VFL Parameter | |
| Laser Launcher Type | LD |
| Output Power | 10mW |
| Distance Range | About 12km |
| Optical Connector | FC/UPC |
| Output Wavelength | 650nm ± 10nm |
| Modulation Frequency | CW / 2Hz |
| Physical Parameters | |
| Interface | Internet port, 3 USB port |
| Display | 7 inch TFT-LCD Screen |
| Battery | 7.4V/4.4Ah lithium battery, continuous 5.5 hours |
| Working Temp | -10°C~+50°C |
| Storage Temp | -20°C~+75°C |
| Dimension | 253×168×73.5mm / 1.5kg |
| Accessories | |
| Standard Accessories | 1* FHO5000 1* Quick guide 1* USB cord 1* 12V AC/DC adapter 1* Battery 1* Software CD 1* FC adapter 1* Carrying case |
