100% Original Swiss S136 Material MTUPC-24 APC8000 Fiber Polishing Fixture By HOMK Exclusive Manufacturing

The MTUPC-24 APC8000 fiber optic polishing jig is IPC Structure, Independent compression of each connector. The jig  pass rate with Interference> = 98% (100% Typical, according to IEC), APPEX OFFET is within 24. It is high stability and good surface quality.

The jig using high quality steel with heated treat, the hardened steel S136 provide long service life. This LC APC8000 polishing fixture can design the jig of SC, FC, ST, LC, MPO and E2000, FA, etc, according to the customer request.

1. It is used in four corners corners fiber polishing machine, to plishing connectors.

2. This jig adopt independent pressurized way, eliminate ferrules show the different length effects on polishing.

3. Each one can hold 24 connectors. It has high production efficiency.

4. The plugs of polishing fixture can be interchanged,extend the life.

5. It has good quality, high efficiency,

6. All kinds of polishing fixture can be customized according by customer requirement.
