Insertion Return Loss Tester(HK-S6)

Details

Insertion return loss tester HK-S6


The insertion return loss tester adopt unique insertion loss warning setting, insertion return loss tester has different display colors to increase testing efficiency linkage of the wavelength of the modes of optical light source and optical power meter, reducing operation procedure, easy to clean with dismountable, design adaptors, various types of test connectors.

The HK-S6 be used for Insertion Loss/Return Loss test of optical fiber, optical passive component, fiber telecommunication system at lab or production line.

Insertion return loss tester Performance:
1. Our this insertion return loss tester has two optional waveband, Measure and display both of RL and IL at the same time
Capable of the being light source and optical power meter.

2. This insertion return loss tester be used for Insertion Loss/Return Loss test of optical fiber, optical passive component, fiber telecommunication system at lab or production line.

3. The insertion return loss tester is easy operation and high accuracy and repeatability.

Optical Return Loss TestOperating Wavelength1310/1550nm
Measurement Range0 ~ 75 dB
Calibrated Wavelength1310/1550nm
Test Accuracy0.25dB
Output Stability0.05dB/hour ( @ 25º C)
Optical InterfaceFC/APC
Optical  Insertion Loss TestCalibrated Wavelength850/1310/1550nm
Measurement Range+3 ~ -80 dBm
Test Accuracy0.25dB
Display ResolutionNon-linear: 0.001dB; inear: 0.001nw/μ W/mW
