Shenzhen Homk Telecom Tech Co., Ltd.

LC-FC Fiber Adapter

Details

LC-FC Fiber Adapter

Product Description

BRIEF INTRODUCTION

Homk provides kinds of Hybrid Adapter, plastic, semi-metal, metal type housing available.


FEATURES
Low insertion loss
Good exchangeability and durability
High temperature stability
All parts compliant with ROHS
polytypic
 APPLICATIONS
Active device termination
Test equipment
Passive optical fiber network
Data processing network
Telecommunication network
CATV, LAN, WAN


SPECIFICATIONS (Hybrid type adapter)


Alignment Sleeve

ZrO2

Housing   Material

Zn-Alloy   or Cu-Ni (metal) & Engineering Plastic Blue (plastic)

Insertion   Loss

0.20dB   max., 0.10dB typ

Durability

500   matings, 0.2dB max. increase

Retention   Force

200~600grams

Operating   Temperature

-40ºC   to +80ºC
