MM SX ESCON patch cord

Details

MM SX ESCON Fiber optical patch cord

Our optical fiber ESCON patch cord is high return loss and low insertion loss ,Insertion loss of ESCON fiber patch cord is less than 0.3dB,Return loss of fiber LC patch cord is UPC more than 55dB ,APC is more than 60dB

Standard: IEC, Telcordia GR-326-CORE

Polish:PC/UPC/APC

Operating temperature range:  -40°C~80°C

Storage temperature range:  -40°C~80°C

Tensile strength: >10kg

Fiber cable diameter: 0.9mm, 2.0mm, 3.0mm fiber is available

Fiber jacket PVC or LSZH cable is available

Fiber FC optic patch cord with excellent changeability and repeatability

Insertion loss

Less   than 0.2dB

Return loss

MM more   than 35dB

SM more   than 55dB

APC more   than 60dB

Repeatability

Less   than 0.2dB

Changeability

Less   than 0.1dB

Operting termperature

-40°C~80°C

Storage temperature

-40°C~80°C

Tensile strength

>10kg

Min.bending radius

35mm

Length

Customized
