MU-MU fiber optic adapter

Details

MU-MU fber optic adapter


Mating sleeve fiber optic adapters allow users to couple from one connector type to another same type. These adapters are comprised of a polymer/metal outer body and inner assembly fitted with a precision   alignment mechanism. These adapters are precision made and manufactured to demanding specifications. The combination of a ceramic/phosphor   bronze alignment sleeves and precision molded polymer housing provides consistent long-term mechanical and optical performance.

Applications:

  • Local Area Networks

  • CATV System

  • Telecommunication Networks

  • Equipment Test

Characteristics:

  1. Low insertion loss, high return loss

  2. Good compatibility

  3. High precision of mechanical dimensions

  4. High reliability & stability

  5. Ceramic or Bronze Sleeve

  6. PC,APC,UPC optional



Specification:



Parameter

Unit

LC, SC, FC, MU, ST, SC-ST, FC-ST, FC-SC, FC-LC, FC-MU

MTRJ

E2000

SM

MM

SM

MM

SM

PC

UPC

APC

PC

PC

UPC

PC

PC

APC

Insertion Loss (Typical)

dB

≤0.3

≤0.2

≤0.3

≤0.2

≤0.3

≤0.2

≤0.2

≤0.3

≤0.3

Return Loss

dB

≥45

≥50

≥60

≥30

≥45

≥50

≥35

≥55

≥75

Exchangeability

dB

≤0.2

≤0.2

≤0.2

Repeatability

dB

≤0.2

≤0.2

≤0.2

Durability

Time

>1000

>1000

>1000

Operating Temperature

-40~75

-40~75

-40~75

Storage Temperature

-45~85

-45~85

-45~85
