Fiber Patch Cord (LC-SC SM SX)
LC-SC patch cord Features:
Low insertion loss, high return loss
High dense connection, easy for operation
High credibility and stability
Good in repeatability and exchangeability
LC-SC patch cord Application:
Testing equipment
FTTX+LAN
Optical fiber CATV
Optical communication system
Telecommunication
LC-SC patch cord Specification:
Parameter | SM(Max) | MM(Max) |
Insertion loss | ≤0.3dB | ≤0.3dB |
| Return loss | ≥50dB | ≥35dB |
Operating temperature | -40℃∽+80℃ | -40℃∽+80℃ |
SC/APC Specification:
Parameter | SM(Max) |
Insertion Loss | ≤0.3dB |
Return Loss | ≥60dB |
Operating temperature | -40℃∽+80℃ |
