Patch cord(SC ST SX MM)

Details

Patch cord(SC ST SX MM)

Fiber Patch cord (SC-ST SX MM)


SC to ST is a fiber optic cable capped at either end with connectors that allow it to be rapidly
and conveniently connected to CATV, an optical switch, or other telecommunication equipment.

 Features:

1.Price-Competitive

2.Low Insertion Loss & PDL

3. Customized lengths(1m/2m/3m)

4.Fiber Options: G.652 /G.657/OM1/OM2/OM3 and PM Panda Fiber

5.Polishing Options: PC/UPC/APC

6.Feature Connector with Ceramic Ferrules



Details:

Parameters

Standard Fiber Cable Assemblies

Fiber Type

SM(G.652/G.657A)

MM(OM1/OM2/OM3)

Jacket Materials

LSZH/OFNR/PVC

Connector Type

SC/LC/ST/LC/MU/MTRJ/MPO/E2000

Ferrule Materials

Ceramic

Testing Wavelengths

1310±30/1550±30nm

850±30/1300±30nm

Insertion Losss(dB)

≤ 0.3dB

≤ 0.3dB

TIA/EIA-455-107

(PC/UPC/APC)

(PC/UPC)

Return Loss(dB)

≥45dB(PC/UPC)

≥35dB(PC/UPC)

TIA/EIA-455-107

≥55dB(APC)

Exchangeability

≤ 0.2dB

Cable Assemblies

Pigtail/Simplex/Duplex/Fan-out Patchcord

Operating Temperature (° C)

-10~ + 70

Storage Temperature (° C)

-40 ~ +85

Package

1unit/bag
