Shenzhen Homk Telecom Tech Co., Ltd.

Patch cord(SC SX)

Details

Fiber Patch cord (SC-SC SM SX)


SC fiber Patch cord has a molded plastic plug casing and a push/pull locking system.

SC to SC is a fiber optic cable capped at either end with connectors that allow it to be rapidly and conveniently connected to CATV, an optical switch, or other telecommunication equipment.

SC patch cord Features:

Low insertion loss, high return loss
High dense connection, easy for operation
High credibility and stability

Good in repeatability and exchangeability

SC patch cord Application:

Testing equipment
FTTX+LAN
Optical fiber CATV
Optical communication system

Telecommunication

SC/UPC patch cord Specification:

Parameter
       SM(Max)        MM(Max)
Insertion loss
      ≤0.3dB
       ≤0.3dB
Return loss

       ≥50dB
       ≥35dB
Operating temperature
  -40℃∽+80℃
  -40℃∽+80℃


SC/APC patch cord Specification:

Parameter

SM(Max)

Insertion Loss

≤0.3dB

Return Loss

≥60dB

Operating temperature

-40℃∽+80℃
