Details
Proskit MT-7501 1mW fiber optic visual fault locator VFL
Product Description
Pros'Kit laser pen is designed for the needs of simple fiber optic testing, provides with constant light mode and flashing mode to quickly test optical line and locate the breakpoints, it is very convenient and reliable.
Features
1 second fast testing
2 modes of testing : constant light and flashing mode
3 types of fiber adapter, suits for SC/FC/ST, LC adapter optional
Specification
Model | MT-7501 | MT-7505 | MT-7510 |
Wavelength | 650 nm±10 nm | ||
Output power | 1 mW | 5 mW | 10 mW |
Laser | CLASS II | CLASS IIIA | CLASS IIIB |
Mesurement distance | 3-5 KM | 6-7 KM | 8-10 KM |
Power supply | AA (1.5 V) x 2 pieces | ||
Optical ports | 2.5mm FC/ST/SC universal | ||
Dimension | 175mm | ||
Operating temp. | -10~+55 ℃ | ||
Storage temp. | -40~+70 ℃ | ||
Optional | LC adapter (5MT-7601-LC) | ||
