SMA-ST Fiber Adapter

Details

SMA-ST Fiber Adapter

Product Description

BRIEF INTRODUCTION

Homk provides kinds of Hybrid Adapter, plastic, semi-metal, metal type housing available.


FEATURES
Low insertion loss
Good exchangeability and durability
High temperature stability
All parts compliant with ROHS
polytypic
 APPLICATIONS
Active device termination
Test equipment
Passive optical fiber network
Data processing network
Telecommunication network
CATV, LAN, WAN
SPECIFICATIONS (Hybrid type adapter)

ITEM

PARAMETER

Applicative   adapter type

SC,LC,FC,ST,E2000,MU,D4,DIN

Fiber   mode

Single   mode

Multi-mode

Adapter   color

Blue,   green, metal

Beige,   metal

Test   wavelength

1310nm,   1550nm

850nm,   1300nm

Insertion   Loss

typical≤0.15dB,Max≤0.20dB

typical≤0.15dB,Max≤0.20dB

Repeatability

≤0.10dB

Interchangeability

≤0.20dB

Durability

≤0.20dB Max change,1000 mating

Channels

Simplex,Duplex,4channels

Body   material

Plastic   or metal

Sleeve   material

Ceramic(ZrO2)   or Customized

Operating   Temperature

-20ºC to +70ºC

Storage   Temperature

-40ºC to +85ºC
