Square Fiber Polishing Film

Details

Fiber polishing film square one 40, 30, 15, 9, 6, 3, 1u, 0.02u etc.

Product features:

The product is made of nano silicon carbide material, with good cutting force and wear resistance. It is suitable for dry polishing and polishing with water or grinding oil.


The specifications of silicon carbide abrasive paper are 40, 30, 15, 9, 6, 3, 1u, etc.

The conventional size of round grinding disc is Φ 127mm (5inch) and Φ 203mm (8inch), and other specifications can be customized according to customer's requirements.

Main uses:


1. The ceramic insert of optical fiber connector is ground and degummed;

2. Fine grinding and polishing of floppy disk head;

3. Grinding and polishing of plastic optical fiber;

4. High precision processing and mirror polishing of various materials.


Grinding process suitable for communication industry:


(1) Grinding process of optical fiber connector (optical fiber connector with plastic sleeve), such as MT-RJ optical fiber connector grinding process: SC30 / 15-sc9-sc6-sc3-sc1 grinding paper, polished with black skin + ceria grinding liquid; suitable for electronic center model and four corner pressure model. The grinding pad is made of glass.

(2) SC30 / SC15 grinding sheet (grinding paper) can be used in the first process of grinding ceramic sleeve such as FC type, SC type, St type and LC type optical fiber connector to achieve the effect of degumming.
