USA RUHR TI-200 E1/Power Meter Tester
TI-200 is a hand-held tester which sets E1, IP Ping (HDLC / PPP / Frame Relay Protocol) and optical power meter in one, can provide quality error of assessing of network comprehensively, alarm and upper business layer testing. Using intelligent or advanced mode of operation, displaying of statistical results directly, for the engineering and maintenance personnel on-site installation, testing and maintenance, saving a lot of time.
Product Feature:
Hand-held 3.5-inch color touch screen, Chinese display
Online, non-online business testing
Non-framing, framing services (PCM-30, PCM-30C, PCM-31, PCM-31C)
2.048 Mbps (N x 64 kbps, N = 1 to 31) rate transmission / reception
Supports IP Ping of E1 (HDLC / PPP / Frame Relay)
It provides E1 self-loop IP Ping function test
BERT Error characteristics test (G.821, G.826, M.2100 / 550)
Alarm generation / error insertion test
Automatically detects the destination IP address
Fully automatic and advanced operating modes
Result Data store / print function
Performance Figure
Connector
BNC Connector：E1 Test Function
Power Meter FC/SC Connector
Status／Warning Instruction
E1 Portion
Test Rate：2.048Mbps、N (Continuation) 和M (Discontinuation) x64Kbps(N&M=1 to 31) Insert／Take out N or Mx 64kbps
Line Code：HDB3&AMI
Picture Format：Unframed、PCM-30、PCM-30c、PCM-31、PCM-31C,conform to ITU-T G.704
Pattern Generator
PRBS:2n-1, n=9, 11,15, 20, 23,comform to ITU-T 0.151 0.152, 0.153
Transmitting End
Internal Clock：2.048MHz±5ppm；Reception:Closing the Signal
Line Code：HDB3 and AMI
Impulse Waveform：Conform to ITU-T G.703, 75ΩUnbalabcex2.37Vbn
Error Insert：BIT、CODE、BIT+CODE; Single or 1x10-1 to 1x10-7 speed
Receiving End
Frequency Range：2.048Mbps±8000bps
Input Sensitivity：0 to -43dB
Return and Loss Performance:ITU-T G.703;Jitter Tolerance
Conform to ITU-T G.823
Measure
E1 Receive Frequency Measurement (Hz and ppm) and Receive Signal Level
Code/BPV Error (Error Counter and Rate) Framing Error (FAS、MFAS and CRC-4 Error Counter and Rate)LOS、Sync Loss、LOF、AIS、FAS、 RAI and MFAS Seconds Counter
G.821 Analysis、G.826、M.2100/ 550 Measure E-bit Error Counter and Rate
IP Ping （E1）Function
Support on E1 Link IP PING test
Support the PPP、HDLC、frame relay routing protocol
Support from the ring on E1 link in IP PING test contact, receiving ,error packets,packet loss and packet loss rate statistics
Set the length 0 to 1500 bytes
The largest number of contract：999999999 pcs
Optical Power Meter
The Wavelength：850nm/1300/1310/1550/1625nm
The Interface：FC/SC/ST、 LC（Optinal）
The Test Range：+26～ -50dBm or +10~ -70dBm
The Probe Typr：InGaAs
The Precision：±0.01dB
General Features
Can store 500 test results
High resolution 3.5 inch color LCD Display,with LED backlight
Internal battery: Smart lithium batter 3200 MA, 12.6V
Battery operating time:6 hours;Charging time:5 hours
Charge:12.6V@2A,90 to 265VAC,50-60Hz
The Enviroment
Operating Temperature: 0℃ to 50℃
Storage Temperature: －20℃ to +70℃
The Temperature: 5% to 90% confensation
Size: 180mmx90mmx40mm
Weight: 0.4kg
