Waterproof PDLC outdoor Fiber Cord PDLC-LC DX Fiber Optic Patch Cords

Details

Waterproof PDLC outdoor Fiber Cord PDLC-LC DX Fiber Optic Patch Cords


Features


Specification:

The PDLC Waterproof patch cord used for outdoor RRU transmitting optical signal and remote fiber feeder etc;

1. Standard Duplex LC connector, well connected with standard LC adaptor

2. Available Single mode and Multimode

3. IP67 protection, salt-mist proof, humidity proof, dust proof

4. Low insertion/return loss, steady optical transmitting.

5. Light weight, waterproof, dustproof, moisture proof, Metal hard housing.



Applications

1. Widely used in FTTA & FTTH

2. Used for 3G 4G base station

3. BBU, RRU, RRH, LTE



Cable Parameters:

Fiber Count

Cable Dimension

mm

Cable Weight

kg/km

Tensile

N

Crush

N/100mm

Min. Bend Radius

mm

Range of Temperature



Long Term

Short Term

Long Term

Short Term

Dynamic

Static

2

7.0

42.3

200

400

1100

2200

20D

10D

-30-+70

Note: 1. All the values in the table, which are for reference only, are subject to change without notice;

2. The cable dimension and weight are subject to the simplex cable of 2.0 outer diameter;

3. D is outer diameter of the round cable;

Structure:

 Waterproof PDLC-FC outdoor Fiber Cord FC PDLC Fiber Optic Patch Cords/jumper

Connector Specification:

ITEM

PARAMETER

Connector type

DLC/UPC . PDLC

Insertion Loss

<=0.3db

Return Loss

>=50db

Fiber mode

Single mode 9/125

Operating wavelength

1310nm, 1550nm

Test wavelength

1310nm, 1550nm

Repeatability

<=0.1

Interchangeability

<=0.2dB

Durability

<=0.2dB

Fiber Length

1m, 2m….. any length optional.

Length and tolerance

10cm

Operating Temperature

-40C ~ +85C

Storage Temperature

-40C ~ +85C
