One-step hand-held Auto Blade Fiber FC-7R cleaver

Details

One-step hand-held Auto Blade Fiber FC-7R cleaver


Features

  • FC-7R: Industry’s Only 1 to 8 Fiber Cleaver with Automatic Blade Rotation

  • Prevents Double Scoring of Fibers

  • Features Automatic Fiber Scrap Collection

  • Can Be Operated With Minimal Steps

  • Works With Sumitomo Fiber Holders

  • Can Be Used for Single Fiber Cleaving or Up to 8 Count Ribbon

  • Rugged Aluminum Alloy Outer Housing

  • Manual Blade Rotation Not Required

  • Blade Height Adjustment Not Required

Description



The FC-7R is the most versatile tool available for optical fiber cleaving. TheFC-7R is the industry’s first and only 1-Step optical fiber cleaver with automatic blade rotation and is ideal for use in fusion splicing, field termination, or any other precision application. It has a simple cleaving operation that can be performed in the palm of the hand, allowing the user to take the cleaver to fiber in limited slack applications. The FC-7R can perform cleaves on single fibers (0.25 to 0.90) and up to 8 count ribbons. A built-in fiber scrap collector handles scrap fibers resulting from the cleaving process. Following a completed cleave, the lid is raised allowing the collector to automatically grab and safely store the fibers. The FC-7R includes an automatic blade rotation feature. With each cleave, the blade is automatically rotated to a new scoring position on the cleaver blade. The automatic blade rotation feature ensures that the user receives the maximum number of precision cleaves from each cleaver blade.

Dimensions

98W x 47D x 58H (mm)

Weight

300g

Coating Diameter

0.25mm - 0.9mm (Single) 0.25mm (Ribbon)

Cladding Diameter

0.125mm

Cleave Length

6mm - 20mm (Single Fiber) 10 - 20mm (Ribbon)

Typical Cleave Angle

0.5 Degrees

Maximum Blade Life

48,000 Fiber Cleaves, 96,000 (After Factory Adjustment)

Number of Steps for Cleave

1

Automatic Scrap Collection

Included
