OM3 Fiber Optic 2.8mm Duplex Flat Twin Black Cord
Parameter | Technical Specification | |
Geometrical Parameters of Polished Ferrules | Curvature Radius(mm) | 10-25 (for 2.50mm PC connectors) |
5-15 (for 2.50mm APC connectors) | ||
Apex Offset(um) | ≤50 | |
Fiber Height(nm) | ±50 | |
Cable Retention(N) | ≥100 | |
Return Loss(dB) (At 1310 & 1550nm) | ≥50(PC) | |
≥60(APC) | ||
Insertion Loss(dB) (At 1310 & 1550nm) | ≤0.2 | |
Temperature Range(°C) | -40~+80 | |
Mechanical Durability (times) | ≥1000 | |
Order Information
Connector Type | Polishing | Fiber Type | Fiber Core | Cable Diameter (or Fan-out Length) | Length | Jacket Color |
FC | PC (SM, MM) | SM1: G652D | SI: Simplex | 0.9mm | customized | Orange |
SC | APC (SM) | SM4: G655 | DU: Duplex | 1.6mm |
| Yellow |
LC | UPC (SM) | SM6: G657 | BUX: (Bunchy, X: 4-96 cores) | 2.0mm |
| customized |
ST |
| OM1: 62.5/125 | RIX: (Ribbon, X: 4-144 cores) | 3.0mm |
|
|
MU |
| OM2: 50/125 | BOX: (Breakout, X: 2-72 cores) |
|
|
|
MTRJ |
| OM3 |
|
|
|
|
E2000 |
|
|
|
|
|
|
