OM2 Fiber Optic Duplex Zipcode Orange Cable
Specifications
Price-Competitive
Low Insertion Loss & PDL
Factory-terminated and Tested
OM2 duplex Fiber Optic ST to LC Patchcord
Features
1.Price-Competitive
2.Low Insertion Loss & PDL
3.Factory-terminated and Tested
4.Fiber Options: G.652 /G.657/OM1/OM2/OM3 and PM Panda Fiber
5.Connector Options: FC/SC/LC/ST/MU/E2000/MT-RJ/MPO/MTP
6.Polishing Options: PC/UPC/APC
7.Feature Connector with Ceramic Ferrules
Applications
1.Access Network
2.Telecom/CATV Systems
3.FTTx
Specifications
Parameters | Standard Fiber Cable Assemblies | |
Fiber Type | SM(G.652/G.657A) | MM(OM1/OM2/OM3) |
Jacket Materials | LSZH/OFNR/PVC | |
Connector Type | SC/LC/ST/LC/MU/MTRJ/MPO/E2000 | |
Ferrule Materials | Ceramic | |
Testing Wavelengths | 1310±30/1550±30nm | 850±30/1300±30nm |
Insertion Losss(dB) | ≤ 0.3dB | ≤ 0.3dB |
Return Loss(dB) | ≥45dB(PC/UPC) | ≥35dB(PC/UPC) |
Exchangeability | ≤ 0.2dB | |
Cable Assemblies | Pigtail/Simplex/Duplex/Fan-out Patchcord | |
Operating Temperature (° C) | -10~ + 70 | |
Storage Temperature (° C) | -40 ~ +85 | |
Package | 1unit/bag | |
*All values specified are with connectors. | ||
Features & Benefits:
1. These cables are halogen-free (= FRNC and LSNH) and watertight and therefore suitable for internal and external use. Consequently splicing can be avoided and the installation gets more cost-effective.
2. These cables are all dielectric (metal-free).
3. Predicted lifetime > 30 years.
4. Suited to SM fiber and MM fiber (50μm and 62.5μm)
5.Suited to SM fiber and MM fiber (50μm and 62.5μm)
