View4M INNO Fiber Fusion Splicer

Details

View4M INNO Fiber Fusion Splicer


Model :View 4M

  • Dimension :135H x 136W x 130D mm

  • Weight : 1.65KG (with battery)

  • Number of Fiber :Single/2-4 Cores (ribbon cable and FTTX cable)

  • Applicable Fibers :SM(ITU-T G.652&G.657) / MM(ITU-T G.651) / DS(ITU-T G.653) / NZDS(ITU-T G.655)

  • Compatible Fiber / Cable :0.25~3.0 mm / Indoor Cable

  • Cleave Length: 10~13 mm

  • Splicing Mode :100 modes

  • Heating Mode:30 modes

  • Typical Splice Loss SM: 0.05dB / MM:0.02dB / DS:0.08dB / NZDS: 0.08dB(ITU-IT and IEC Standard)

  • Return Loss :>>60dB

  • Lighting :3 White LEDs

  • Splicing Time Auto mode : 14 sec

  • Estimated Splice Loss :Available

  • Protection Sleeve Length: 30 40 50 60 mm

  • Heating Time Typical heating time: 20 sec

  • Results Storage :The last 2000 results

  • Tension Test :1.96~2.25N

  • Operating Condition Operating Altitude: 0~5000m above sea level, 0~95% relative humidity, -20~50°C, Max Wind 15m/s

  • Storage Condition : 0~95% relative humidity, -20~60°C,Battery:-20~30°C

  • Display: 90° bi-directional view, 4.3” Color High Resolution Display

  • Fiber View & Magnification :X, Y, XY, X/Y : 520X Magnification

  • Power Supply :AC Input 100-240V, DC Input 9-14V

  • No. of Splice / Heating with Battery :3800mAh Battery Capacity, Typical 85 times (Splice+Heat)

  • Operating Methods :Button / Touch screen

  • Automatic Calibration : Automatic arc calibration by air pressure and temperature

  • Electrode Life : 3500 arcs, can be extended by using an electrode grinder

  • Terminal USB : 2.0 / MINI USB / HDMI
