Details
HOMK 40G QSFP+ Passive Copper Cables are high performance,cost effective I/O solutions for 40G LAN, HPC and SAN applications.
The QSFP+ passive copper cables are compliant with SFF-8436, QSFP+ MSA and IEEE P802.3ba 40GBASE-CR4. It is offer a low power consumption,short reach intercon- nect applications. The cable each lane is capable of transmitting data at rates up to 10Gb/s, providing an aggregated rate of 40Gb/s.
40G QSFP+ Passive Copper Cables are customized for an ultra-high performance, cost effective cable solution in 40-Gigabit speed applications including switched fabric I/O, switches, routers, data storage arrays, and high performance computer (HPC) clusters.
Standard
10 Gigabit Ethernet 4
0 Gigabit Ethernet
InfiniBand4x SDR, DDR, QDR
2, 4, 8, 10 Gigabit Fiber Channel
Fiber Channel over Ethernet SAS,Servers,Hubs,Switches,Routers
SFP+ DAC, 40G DAC, DAC Cable
Features
QSFP+ conforms to the Small Form Factor SFF-8436
4-Channel Full-Duplex Passive Copper Cable Transceiver
Support for multi-gigabit data rates :1 Gb/s - 10 Gb/s (per channel)
Maximum aggregate data rate: 40 Gb/s (4 x 10Gb/s)
Copper link length up to 5m (passive limiting)
High-Density QSFP 38-PIN Connector
Power Supply :+3.3V
Low power consumption: 0.02 W (typ.)
I2C based two-wire serial interface for EEPROM signature which can be customized
Temperature Range: 0~ 70 °C
Applications
10 Gigabit Ethernet
40 Gigabit Ethernet
InfiniBand4x SDR, DDR, QDR
2, 4, 8, 10 Gigabit Fiber Channel
Fiber Channel over Ethernet SAS,Servers,Hubs,Switches,Routers
QSFP+ DAC, 40G DAC, DAC Cable
