BML-205 VFL

Details

BML-205 VFL


The 650nm Pen-type Visual Fault Finder is specially designed for field personnel who need an efficient and economical tool for fiber tracing, fiber routing and continuity cheching in an optical network during and after installation. It includes: Finding the breakpoint, poor connections, bending or cracking in fiber optic cables. Finding the faults of OTDR 2.5mm universal connector Operates either in CW or Pulsed Constant output power Lower Battery warning Long battery life(up to 60 hours) Specifications: Wavelength  650nm±10nm Emitter Type  FP-LD laser Output power  10mW connector  2.5mm universal adapter Working mode Both CW and Pules available Operating  temperature  -10~+45 °C Storage  temperature  -40~+70 °C Power 2pcs AA battery Working hours   60 Weight 110g (excluding batteries) Dimension (mm) 220 X 27 Package Include 1 x Fiber Checker 1 x Black bag
