Fiber optical power meter OPM +6 -70dbm Proskit Mt-7601
Fiber Optic Power Meter
An essential fiber test instrument used for absolute optical power measurement as well as fiber optic relative loss measurement. Easy to use for Datacom, Telecommunication networks & FTTx applications.
Features:
Free from any complicated transformation (Adapts to FC/SC/ST connectors)
Energy saving (Automatically auto power off after 10min of no operation.)
Multi wavelength measurement (850nm/1300nm/1310nm/1490nm/1550nm/1625nm)
Supports night operation (Comfortable LCD backlight display)
New REF user-defined (Can store the current laser source as a new reference value)
Well protected and portable design (Additional shock-proof cover & pouch bag)
Specifications
| Detector Type | InGaAs |
| Optical Connector | FC/SC/ST& 2.5mm Universal |
| Calibrated Wavelengths | 850,1300, 1310, 1490, 1550, 1625 |
| Measurement Range | +6 -70 dBm |
| Accuracy | ± 0.2 dB |
| Power Measurement Linearity | ±2.0% |
| Display Resolution | +6 - -60dBm: 0.01 dB. -60 - -70dBm: 0.1 dB |
| Power Display Units | dBm , mW, uW, nW |
| Reference comparison value | Yes |
| Modulation Detection | 270Hz - 1 KHz - 2KHz (850, 1300, 1310, 1490, 1550, 1625) |
| Operation voice prompts | Yes |
| Backlight | Yes |
| Automatic Power Off | 10 min.(Can be cancelled) |
| Low Battery Warning | Low battery energy |
| Body protection | Yes |
| Battery Life | >160 hours |
| Operating Temperature | -10~+60"C, <90% |
| Storage Temperature | -20- +70°C, <90% |
| Power source | AA/LR61.5V x 2 pcs |
| Size | 165 x 80 x 35 mm |
| Weight | 180g (with o battery) |
| Optional Accessory | LC adaptor (5MT-7601-LC) |
