Fluke Test Cat6A FTP/STP/UTP Shielded Cable
Product Description
Product Name | SHIELDED TWISTED CAT6A SFTP NETWORK INSTALLATION CABLE | ||
Inner Conductor | Material | Bare Copper Pass FLUKE Test | |
Diameter | 0.58mm ± 0.01mm ( 23AWG ) | ||
Insulation ( Dielectric ) | Material | Skin Foam PE ( Polyethylene ) | |
Thickness | ≥ 0.28mm | ||
Diameter | 1.35mm ± 0.02mm | ||
Drain Wire | Material | Tinned Copper/ Bare Copper | |
Diameter | 0.5mm ± 0.01mm | ||
Shielded Layer | First Layer | Aluminum Foil Per Pair | |
Second Layer | AL-MA Alloy Braid | ||
Twisted Pair | N/A | Pair 1: Blue, White/ Blue | |
Pair 2: Orange, White/ Orange | |||
Pair 3: Green, White/ Green | |||
Pair 4: Brown, White/ Brown | |||
Outer Jacket | Material | LSZH | |
Thickness | ≥ 0.66mm | ||
Nominal O.D | 7.80mm ± 0.10mm | ||
Reference Standard | Category 7 UL444, ANSI/ TIA/ EIA 568B & ISO/ IEC11801 Stanard | ||
Rated Temperature | -20℃ to +70℃ | ||
Supports Transmission | Digital and analogue voice, data and video signal | ||
