Fullaxs fiber optic outdoor waterproof patch cord/Full-axs patchcord/Fullaxs connector/IP67 waterproof connector

Details

Fullaxs fiber optic outdoor waterproof patch cord/Full-axs patchcord/Fullaxs connector/IP67 waterproof connector

Outdoor fiber optic Patch Cord is called waterproof patch cord ,it usually together with waterproof  boot ,can be laid in all kinds of environmental extremes and more they have passed testes like salt mist, vibration and shock and meet protection class IP67. They are well suited for Industrial and Aerospace and Defense applications.



Key Features

Low Insertion Loss and high return loss

Rugged, excellent kink and crush resistant

Stainless steel tube

Flame retardant characteristics meet the requirements of relevant standards

Available for LC, SC, ST, FC, etc standard connectors

ROHS, REACH and SVHC compliant



How to Choose The Right Fiber Optic Cable Type

esignation

Fiber Dia.
(um)

Type

Fast Ethernet
100BASE-FX

1 Gigabit Ethernet
1000BASE-SX

1 Gigabit Ethernet
1000BASE-LX

10 Gigabit Ethernet
10GBASE

40 Gigabet Ethernet
40GBASE-SR4

100 Gigabet Ethernet
100GBASE-SR4

OM1

62.5/125

Multimode

2000 Meters

275 Meters

550 Meters
(mode conditioning patch cable required)

33 Meters

Not supported

Not supported

OM2

50/125

Multimode

550 Meters

82 Meters

Not supported

Not supported

OM3 (Laser Optimized)

50/125

Multimode

550 Meters

300 Meters

100 Meters

100 Meters

OM4 (Laser Optimized)

50/125

Multimode

400 Meters

150 Meters

150 Meters

Singlemode

9/125

Singlemode

5km at 1310nm

5km at 1310nm

10km at 1310nm





Optical performance



Insertion loss

IEC61300-3-34

Singlemode

Typ. ≤0.30dB

97% ≤0.45dB

Multimode

Typ. ≤0.30dB

97% ≤0.50dB

Return loss

Singlemode

≥50dB




NOTE:

Cable length: Any length can be customized as you required.

Cable jacket: The default jacket is PVC. LSZH, OFNP, OFNR can be customized.

Cable connector: SMA905, VF45, MU and D4 are available.

Cable color: Red, Purple, White, Black, Orange and Pink can be customized. As to customized colors, our MOQ is 1000 meters.
