SC OM4 DX Fiber Optic Adapter Pink
SC Fiber Optic Adapter, LC Fiber Optic Adapter, FC Fiber Optic Adapter, ST Fiber Opitc Adapter, MU Fiber Optic Adapter, MTRJ Fiber Optic Adapter, E2000 Fiber Optic Adapter, D4 Fiber Optic Adapter Feature: Good inerchangeability Environmentally Stable and Reliable Accurate Size Excellent Return Loss Applicable standard: IEC 61754-13 Complete Hybrid adapter Technical Standard: Insertion Loss ≤0.2dB Retentiveness 200-600g Mating Durability1000 times≤ 0.2dB Exchangeability: < 0.2dB Salt Spray: ≤ 0.2dB Sleeve material: ceramic / metal Temperature Rang -40 to +85
| Parameter | ||
| Mode | S.M (Zroz) | M.M (P.B) |
| Insertion Loss | ≤0.2 dB | ≤0.3 dB |
| Mating Durability(500 times) | ≤0.2 dB | |
| Operating Temperature(°C) | -40°C~+75°C | |
| Parameter | ||
| Return Loss | ≥45 dB ( SPC ) , ≥55 dB ( UPC ),≥65 dB ( APC ) | |
| Attenuation Tolerance (dB) | 1-10dB<±1.0dB | |
| 11-25dB<±10% | ||
| 1-10dB<±0.5dB | ||
| 11-25dB<±5% | ||
| Operating Wavelength (nm) | 1310±10nm | |
| 1550±10nm | ||
| 1310 and 1550±10nm | ||
| Operating Temperature(°C) | -40°C+~75°C | |
