Shenzhen Homk Telecom Tech Co., Ltd.

SC optical fiber adapter

Details

SC optical fiber adapter


SC Fiber Optic Adapter, LC Fiber Optic Adapter, FC Fiber Optic Adapter, ST Fiber Opitc Adapter, MU Fiber Optic Adapter, MTRJ Fiber Optic Adapter, E2000 Fiber Optic Adapter, D4 Fiber Optic Adapter
   Good inerchangeability
   Environmentally Stable and Reliable
   Accurate Size
   Excellent Return Loss
   Applicable standard: IEC 61754-13
   Complete Hybrid adapter
   Technical Standard:
   Insertion Loss ≤0.2dB
   Retentiveness 200-600g
   Mating Durability1000 times≤ 0.2dB
   Exchangeability: < 0.2dB
   Salt Spray: &le; 0.2dB
   Sleeve material: ceramic / metal
   Temperature Rang -40 to +85


SPECIFICATIONS (Hybrid type adapter)

ITEMPARAMETER
Applicative adapter typeSC,LC,FC,ST,MU,D4,DIN
Fiber modeSingle modeMulti-mode
Adapter colorBlue, green, metalBeige, metal
Test wavelength1310nm, 1550nm850nm, 1300nm
Insertion Losstypical&le;0.15dB,Max&le;0.20dBtypical&le;0.15dB,Max&le;0.20dB
Repeatability&le;0.10dB
Interchangeability&le;0.20dB
Durability&le;0.20dB Max change,1000 mating
ChannelsSimplex,Duplex,4channels
Body materialPlastic or metal
Sleeve materialCeramic(ZrO2) or Customized
Operating Temperature-20&ordm;C to +70&ordm;C
Storage Temperature-40&ordm;C to +85&ordm;C
