Waterproof-cable
Waterproof-cable Application：
Adopted to Outdoor distribution.
Connected to connectors of various models interconnect.
Can be installed conveniently and operated simply.
Waterproof-cable Characteristics：
More single-core cable design.
Steel tape armoured.
Waterproof and applicable scurviness environment.
Technical Parameters: | ||||||||||
Cable Count | Out sheath | Weight | Minimum allowable Tensile Strength | minimum allowable Crush Load | Minimum Bending Radius | Storage | ||||
（MM) | （KG) | short term | long term | short term | long term | short term | long term | （℃） | ||
2 | 10.5 | 155.00 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40+60 | |
4 | 10.5 | 155.00 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40+60 | |
6 | 11.5 | 185.00 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40+60 | |
12 | 12.5 | 225.00 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40+60 | |
| ||||||||||
Optical Characteristics | ||||||||||
Fiber Sort | Multimode | G.651 | A1a:50/125 | Graded-index fiber | ||||||
A1b:62.5/125 | ||||||||||
Singlemode | G.652(A、B、C、D） | B1.1:Conventional fiber | ||||||||
G.653 | B2: Zero dispersion shifted | |||||||||
G.654 | B1.2 :Cut-off wavelength shifted | |||||||||
G.655 | B4: Main technical data for positive | |||||||||
