Details
Korea INNO IFS-15F Fusion Splicer
| Weight | 1.82 KG without battery |
|---|---|
| Applicable Fibers | SM(ITU-TG.652)/MM(ITU-TG.651)/DS(ITU-TG.653)/NZDS(ITU-TG.655)/ITU-TG.657A/ITU-TG.657B |
| Compatible Fiber/Cable | 0.25mm/0.9mm Exclusive Mode: 80μm Fiber/ 980μm Fiber |
| Fiber Count | Single Core |
| Fiber Holder | Replaceable (Standard: FH-10,Optional: FH-40, FH-ST, FH-SC, FH-30) |
| Fiber Diameter | Cladding:80-150μm /Coating:100-1000μm |
| Fiber Cleave Length | Diameter 250μm-1000μm: cleave length 8-16mm |
| Splice Mode | Max/Preset 64/24 |
| Typical Splice Loss | SM:0.02dB/MM:0.01dB/DS:0.04dB/NZDS:0.04dB/G.657:0.02dB (ITU-T Test) |
| Return Loss | >>60dB |
| Splicing Time | SM Quick Mode:7second |
| Estimated Splice Loss | Yes |
| Attenuation Splicing | 0.1dB-20dB (0.1dB step) |
| Heat Oven/Heating Time | Heat Mode: 32/Heating Time (Typical): 35 second |
| Applicable Protection Sleeve Length | 10mm, 20mm, 30mm, 40mm, 50mm, 60mm |
| Results Storage | The last 2000 results |
| Mechanical Proof Test | 1.96~2.25N [Based on the fiber count] |
| Operating Condition | Operating Altitude:0-5000meter above sea level, 95% relative humidity, - 10~50°C, Max Wind 15m/s |
| Storage Condition | 0~95% relative humidity, -40~80°C, Battery: -20~ 30 °C |
| Size/ Color | 155*130*137(L*W*H)/ Luxury silver |
| Display | 2 Cameras and 4.3 inch color LCD monitor (with high strength and shock-proof protect surface) |
| Fiber View & Magnification | X/Y 300X, 180X |
| Power | DC 18V Power Supply |
| No of splice/Heating with Battery | No Battery |
| Electrode | 2500 Times Splicing |
| Terminal | USB 2.0/RS232 (for storage and upgrading) |
| Other Functions | IFS-15F Exclusive Software for factory/80μm&980 Fiber Splice Mode/Record and Export the splice data / Splicing No. display/EDF Fiber Splicing |
| MODEL NO. | QTY. | |
|---|---|---|
| IFS-15F Splicer | IFS-15F | 1 |
| High Precision Cleaver | VF-15H | 1 |
| Cooling Tray | CG-22 | 1 |
| Power Cable | ACC-25 | 1 |
| AC Adapter | JS-126300-X | 1 |
| Electrode | E-27 | 2 |
| CD | - | 1 |
| HCK Working Table | HCK-1 | 1 |
| HCK Carrying Case | NBX-35 | 1 |
| Fiber Holder | FH-40, FH-ST, FH-SC, FH-30 | Optional |
