View6S INNO Fiber Fusion Splicer
View 6S, a core-alignment fusion splicer with the world’s highest fiber image magnification rate, is the most dependable fusion splicer in the market. View 6S’s 5 inch high-resolution color LCD touch screen with user-friendly intuitive GUI (Graphical User Interface) offers large and clear fiber images to users. By double-tapping the screen, users can Zoom In & Out the image to the world’s highest magnification of 520x. View 6S offers maximum work efficiency through the fast heating time of 13s. View 6S brings satisfactory working experience to its users in FTTx field, which is compatible with being widely used fiber-optic cables, and short v-groove length makes the splicer capable of splicing 5mm cleave length suitable for splice-on connector. Moreover, the 3 LED lights provide bright splice condition to the users working under dark environments. View 6S is the new industry standard of core-alignment splicer in the telecommunications industry.
Features
Core Alignment Splicing Method with DACAS (Digital Analysis Core Alignment System)
5” High-Resolution Color LCD Touch Screen
User-friendly Smart GUI
Double Tap to Zoom in & out
Fast Heating Time
Short Cleave Length Splicing Capability
Detachable SOC Holder and Heating Oven
High Capacity Battery
3 Bright LEDs and Illuminated Keypads For Dark Environment
Ceramic Clamp for Improved Durability
Easy to Replace Electrodes
Protective Cover
Harsh Weather Conditions Adaptability
Display
5” High-Resolution Color LCD Touch Screen
The View series certainly outdoes the other splicers’ viewing experience.
Measuring a vast 5 inches across, the color LCD display has the highest resolution of 800 x 480 with very wide viewing angles.
Magnification
Double Tap to Zoom in out
By double-tapping the screen, users can zoom in the fiber image to the industry’s highest magnification of 520X.
So INNO Instrument achieves that fiber condition can be easily inspected with unaided eyes.
Interface
User-friendly Smart GUI
The advanced splicing functionality is available through clear options in tile-based design, so experts and even novices can understand its operation without assistance or special training.
Heating Performance
Fast Heating Time of 13 sec
View 6s has significantly increased the speed of heating to 13 sec, which delivers maximum work efficiency.
SOC Compatibility
Detachable SOC Holder and Heating Oven
View 6s’s SOC compatibility with Detachable SOC holder and heating oven delivers satisfactory experiences to users in FTTx field.
Battery
170 Times (Splice & Heat).
The battery capacity is 4200mAH. Also, the battery life will be demonstrated via 5 stage of battery indicator
LED light
3 Bright LEDs For Dark Environment
Even in a dark environment, the industry’s first 3 LEDs are just bright enough to cast a light on the fiber holders as well as the splice point.
Clamp
Ceramic Clamp for Improved Durability
Ceramic-made fiber clamp can secure the durability of stripped fiber by minimizing the damage on the fiber surface.
Electrode Cover
User-friendly Electrode Cover
Specially designed electrode covers make users replace electrodes in a much easier and faster way without any tools.
Dimensions
Height: 5.98 inches (152 mm)
Width: 5.78 inches (147 mm)
Depth: 6.88 inches (175 mm)
