ILSINTECH Swift KF4 Active V-groove Alignment Fusion Splicer

Details

ILSINTECH Swift KF4 Active V-groove Alignment Fusion Splicer


Swift  KF4 is very versatile and super accurate active cladding alignment  fusion splicer that satisfies every aspect of splicing requirement. With  slim, yet rugged and extremely light, budget priced Swift KF4 assures users of convenient and stable process as well as high performance.



SPECIFICATIONS

CategoryDescriptionFiber alignmentActive V-Groove AlignmentApplicable type of fibers0.25mm, 0.9mm, 2.0mm, 3.0mm, Indoor cableFiber countSingle fiberApplicable fiber dimensionsCladding diameter: 125um / Coating diameter: 150um~3mmFiber setting and cleaved length5mm to 16mmSplicing modesSplice mode: 300, Heater mode:100Typical Splice LossSM: 0.02dB, MM: 0.01dB, DS: 0.04dB, NZDS: 0.04dBReturn loss> 60dBSplicing TimeTypical 7sec (Standard SM, SM-SM mode)Splice loss estimateAvailableSleeve heating timeTypical 13sec with IS-60 mode, IS-60 sleeveApplicable protection sleeve40mm,60mm and micro sleevesStorage of splice resultDate : 5,000 Up to, Image: 5,000 Up toTension test1.96N to 2.25NOperating conditionAltitude: 5,000m above sea level, Temperature: -10℃~50℃, Humidity: 0~95%,Wind: 15m/s, non-condensing, dust proof, water proof, shock proofStorage conditionTemperature: -40℃~80℃, Humidity: 0~95%Dimension124(W)x189(L)x75(H)mm(Without rubber protector)Weight1.1kg(Including battery)Viewing method and displayTwo CMOS cameras and 4,3-inch color LCD monitorFiber view and magnificationX/Y : 130X MAX:260XPower supplyLi-ion Battery(DC 14.8V, 3400mAh), 100 ~ 240V AC ChargerNo.of splice cycles with batteryTypical 200 cyclesElectrode lifeMore than 3,000 timesTerminalsUSB
STANDARD PACKAGE

CategoryModelQ’tyArc Fusion SplicerKF41Battery AdapterFY17010001Spare ElectrodeEI-241pairCooling TrayCT-01(40mm)1User Guide CD-1Carrying CaseSoft Case(ILST-SS03 L)1BatteryKF-34001CleaverCS-011Alcohol DispenserPP1Manual StripperCF-021USB Cable-1
